LQM-241W
Available while suppies last

24” 1920 x 1080 Native HD LCD Quad Split Display

The LQM-241W is a high quality 24 inch Quad-Split Monitor sharing a majority of the advanced functionality found in the LVM-243W. The LQM- 241W supports 4 HD/SD-SDI inputs at a time in quad split mode and can also display any additional sources full screen or as one of the Quad Split Windows. The LQM-241W also features 4 HD/SD-SDI outputs as well as hosting advanced Waveform and Vectorscope functions.

LQM-241W Specifications

24” 1920 x 1080 Native HD LCD Quad Split Display

The LQM-241W is a high quality 24 inch Quad-Split Monitor sharing a majority of the advanced functionality found in the LVM-243W. The LQM- 241W supports 4 HD/SD-SDI inputs at a time in quad split mode and can also display any additional sources full screen or as one of the Quad Split Windows. The LQM-241W also features 4 HD/SD-SDI outputs as well as hosting advanced Waveform and Vectorscope functions.

Display/

Size:24
Resolution:1920 X 1200 (16 : 10)
Pixe Pitch:0.270mm
Color Depth:16.7M
Viewing Angle:178°(H) / 178°(V)
Luminance:300cd/m2
Contrast Ratio:1000:1
Display Area:518(H) x 324(V) mm

Input/

1 X BNC : Analog Input (Composite)
3 X BNC : Analog Input (Component)
4 X BNC : HD SDI A/B/C/D Channel Input
1 X HDMI : HDMI Input
1 X DVI : DVI Input

LQM-241W Image
LQM-241W ImageLQM-241W Image

/FPGA Functions

1:1 Pixel Mapping Modes for SD/HD
Audio Level Meter Display
Blue Only
H/V Delay
Key Lock
Marker
Mono
Time Code Display
UMD
Various Scan Modes
Waveform/Vector

/Output

1 X BNC : Analog Output (Composite)
3 X BNC : Analog Output (Component)
4 X BNC : HD SDI A/B/C/D Channel Output
